834FRB - Black Flame Retardant Epoxy
This product has been discontinued.
This product has been replaced with our 834HTC – High Thermal Conductivity Epoxy
834FRB potting and encapsulating compound is a black, flame retardant, low viscosity two-part epoxy that offers extreme environmental, mechanical and physical protection for printed circuit boards and electronic assemblies. This product is designed for applications where mechanical strength and self-extinguishing are required. Due to its low mixed viscosity, it can easily penetrate small gaps and cavities. It also provides excellent electrical insulation and protects components from static discharges, vibration, abrasion, thermal shock, environmental humidity, salt water, fungus, and many harsh chemicals. This epoxy has a convenient 2:1 volume mix ratio, making it compatible with most dispensing equipment. 834FRB can be cured at room temperature or higher.
Features & Benefits
- Certified UL 94V-0 (File # E334302)
- Compliant with UL 746A
- Convenient 2A:1B volume mix ratio
- Low mixed viscosity of 2 600 cP
- Very high compressive and tensile strength
- Excellent adhesion to a wide variety of substrates including metals, composites, glass, ceramics, and many plastics
- High Comparative Tracking Index (>600 V, PLC=0)
- Excellent electrical insulating characteristics
- Solvent-free
| Catalog Number | Sizes | Packaging |
|---|---|---|
| 834FRB-375ML | 375 mL (12.7 fl oz) | 2 Bottle kit |
| 834FRB-3L | 2.55 L (0.68 gal) | 3 Can kit |
| 834FRB-60L | 60 L (16 gal) | 3 Pail kit |
Technical Documents
Safety Data Sheet
 |
WARNING! This product can expose you to chemicals including Antimony oxide, which is known to the State of California to cause cancer, and N-methylpyrrolidone, which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov. |
